Contact Material: Copper Alloy C5210-EH Standard Insulator Material: LCP, UL94V-0, Black Contact Terminal: Copper Alloy C5210-EH Metallic Shell: Stainless steel SUS304 Actuator Material: LCP, UL94V-0, Black
Plating
Contact Terminal Underplating: 50µ" Min. nickel all over Contact Plating: Gold Flash Solder Area: Gold Flash Solder Tail: Gold Flash Metallic Shell: 50µ" Min. nickel all over - Solder area gold flash
Electrical
Voltage Rating: 30 V Current Rating: 0.5 Amp Contact Resistance: Initial 100mΩ Max, Final 150mΩ Max Insulation resistance: 1000MΩ Max Dielectric withstanding voltage: 500V AC for 1 minute between adjacent terminal, no breakdown
Mechanical
Durability: 3,000 Cycles
Environmental and Processing
Operating Temperature: -40°C to +85°C Solder Temperature: Peak temp 255°C (-0/+5°C) Maximum (5 seconds)
