Contact Material: Copper Alloy Standard Insulator Material: High Temperature Thermoplastic Housing Material: High-Temp Plastic (UL94V-0), Black Contact Terminal: Copper Alloy Metallic Shell: Stainless Steel Cover Shell: Stainless Steel
Plating
Underplating: Nickel Contact Plating: Gold Flash over Nickel Solder Tail: Gold Flash over Nickel Metallic Shell: Solder area gold flash over nickel
Electrical
Voltage Rating: 30V AC/DC Current Rating: 1.0A AC/DC Max Contact Resistance: 100mΩ Max Insulation resistance: 1000MΩ Min at 500V DC for 1 minute between adjacent terminals Dielectric withstanding voltage: 500V AC for 1 minute
Mechanical
Durability: 5,000 cycles
Environmental and Processing
Operating Temperature: -40°C to +85°C Solder Temperature: Peak temp 255°C (+5°/-0°C) Maximum (5 seconds)
