Contact terminal plating Underplating: 50µ" Min. nickel all over Contact Plating: Gold Flash Solder Area: Gold flash Metallic shell plating Underplating: 50µ" Min. nickel all over Solder Area: Gold Flash
Electrical
Voltage Rating: 125 V AC (RMS) Current Rating: 0.5A Contact Resistance: 100mΩ Max Insulation resistance: 1000MΩ MIN at 500V DC Dielectric withstanding voltage: 500V AC for 1 minute between adjacent terminal, no breakdown
Mechanical
Durability: 5,000 cycles
Environmental and Processing
Operating Temperature: -40°C to +85°C Solder Temperature: Peak temp 260°C (+0/-5°C) Maximum (5 seconds)
