Contact Plating: Gold Flash over 50µ" Nickel Solder Tail: Gold Flash Metallic Shell: 30µ" Nickel over all
Electrical
Voltage Rating: 30V AC/DC Current Rating: 0.5A Contact Resistance: 100mΩ Max Insulation resistance: 1000MΩ MIN at 500V DC Dielectric withstanding voltage: 500V AC for 1 minute between adjacent terminal, no breakdown
Mechanical
Durability: 5,000 cycles
Environmental and Processing
Operating Temperature: -40°C to +75°C Solder Temperature: Peak temp 260°C (+0/-5°C) Maximum (5 seconds)
